Angular Contact Ball Bearings
Overview
- Angular contact ball bearings are engineered to carry combined radial and axial loads by utilizing a precisely ground raceway with a defined contact angle—typically 15°, 25°, or 40°. Unlike deep groove bearings with near-zero contact angles, this geometry enables superior axial load capacity and improved stiffness under demanding operating conditions.
- Talos Bearing supplies ISO 15 boundary dimension angular contact ball bearings in both standard and high-precision grades (P5 / P4). These bearings are designed for a wide range of industrial applications, from general-purpose pumps and gearboxes to high-speed CNC spindle systems operating at elevated dn values, where accuracy, rigidity, and thermal stability are critical.
- The range covers both single and matched set configurations, enabling engineers to optimize performance for speed, load distribution, and system rigidity in advanced mechanical designs.
Products
Interchangeable With : SKF、NSK
-
The 7006C angular contact ball bearing is a high-precision single-row bearing designed for machine tool spindles and high-speed precision equipment....
（Can’t find the product you need? Click the button to contact us! ）
Product Series Table
Single-Row 70 / 72 / 73
The most common configuration. Supports combined radial load and axial load in one direction. Often arranged in matched pairs (DB, DF, DT) for bidirectional capacity.
| Series | Bore Range | Contact Angle | Configuration | Typical Application |
|---|---|---|---|---|
| 70.. (Extra Light) | 4–200 mm | 15° / 25° | Single, or paired (DB/DF/DT) | High-speed spindles, small motors |
| 72.. (Light) | 8–200 mm | 15° / 25° / 40° | Single, or paired (DB/DF/DT) | Pumps, gearboxes, machine tools |
| 73.. (Medium) | 10–200 mm | 15° / 25° / 40° | Single, or paired (DB/DF/DT) | Conveyors, agricultural machinery |
Double-Row 32 / 33
A single integrated unit equivalent to two single-row bearings arranged back-to-back. Handles radial load plus axial load in both directions within a more compact axial footprint than a duplex pair.
| Series | Bore Range | Contact Angle | Configuration | Typical Application |
|---|---|---|---|---|
| 32.. | 10–200 mm | 30° | Integral double-row | Wheel hubs, pumps, gearboxes |
| 33.. | 15–110 mm | 30° | Integral double-row (wider) | Higher radial load applications |
Four-Point Contact QJ2 / QJ3
Single-row design with a split inner ring, allowing the balls to contact the races at four points. Supports heavy axial load in both directions plus radial load — in the same axial footprint as a single-row bearing.
| Series | Bore Range | Contact Angle | Configuration | Typical Application |
|---|---|---|---|---|
| QJ2.. | 10–140 mm | 35° | Split inner ring, single row | Compact bidirectional thrust + radial, gearboxes |
| QJ3.. | 15–160 mm | 35° | Split inner ring, single row (heavier) | Heavy machinery, pumps, compressors |
Quick Selection Guidance
- Axial load in one direction only, often at high speed: Single-row (70 / 72 / 73 series)
- Axial load in both directions, space isn't tight: Single-row pair (DB) or Double-row (32 / 33 series)
- Axial load in both directions, space is limited: Four-point contact (QJ series) — same footprint as a single-row bearing
Applications & Industries
Proven in Demanding Industries
- Machine Tools: Spindles, high-speed machining centers (high rigidity & precision).
- Aerospace: Landing gear, engines, and flight control systems.
- Automotive: Wheel hubs, transmissions, and electric motors.
- Robotics & Automation: High-precision joints and actuators.
- Pumps & Compressors: Reliable operation under combined loads.
- Medical Equipment: Quiet, smooth, and precise performance.
Our bearings help you achieve higher productivity and reliability.
FAQs
What contact angles are available?
Talos Bearing Angular Contact Ball Bearings are available in several contact angle configurations:
- 15° – High-speed applications
- 25° – Balanced speed and load performance
- 40° – Heavy axial load applications
The optimal contact angle depends on your operating conditions and load requirements.
What materials are used in Talos Bearing Angular Contact Ball Bearings?
Talos Bearing products are manufactured using premium bearing steel with advanced heat treatment processes to ensure excellent wear resistance, durability, and long service life.
Optional cage materials include:
- Pressed Steel
- Machined Brass
- Polyamide (Nylon)
What precision grades are available?
Talos Bearing can supply Angular Contact Ball Bearings in:
- P0 (Standard)
- P6
- P5
- P4 (High Precision)
The appropriate precision grade depends on your application’s speed and accuracy requirements.
How do I choose the right Angular Contact Ball Bearing?
When selecting a bearing, consider:
- Shaft and housing dimensions
- Radial and axial loads
- Operating speed
- Working temperature
- Lubrication method
- Required precision level
Our engineering team can help you select the most suitable bearing for your application.
Are your angular contact ball bearings interchangeable with SKF, NSK, FAG, or NTN?
Yes — boundary dimensions follow ISO 15, so our bearings are dimensionally interchangeable with major brands. Always confirm contact angle, precision grade, and preload class against the original part to ensure functional equivalence, not just dimensional fit.
